LED Linear Light

Introduction

Our LED Linear Light shell is constructed from durable aluminum alloy, giving it a sleek and modern appearance. The design is simple yet sophisticated, with clean lines that create a visually pleasing effect. To enhance its longevity, the lamp is coated with an electrostatic plastic spray that adds resistance to high temperatures and harsh weather conditions.
We have also incorporated an imported anodized aluminum plate to create an effective reflector that maximizes light output. This results in better illumination and a brighter, more efficient lighting solution. In addition, our LED Linear Light is incredibly energy-efficient, with savings of over 60% compared to traditional fluorescent tubes. This helps to reduce unnecessary energy consumption and contributes to a more sustainable future.

Feature

Our LED Linear Light stands out with its utilization of new light sources, known for their high brightness, long lifespan, and minimal light decay. Moreover, we take pride in the exceptional waterproof performance of our products. With a thorough application of glue and waterproofing measures, our LED Linear Light achieves an impressive waterproof rating of IP67. Additionally, our unique arc design adds a touch of modernity and sophistication to the overall appearance. This three-dimensional design is aesthetically pleasing and visually attractive. Lastly, the aluminum panels we offer are not only easy to install but also require minimal effort for maintenance, ensuring a hassle-free experience for our customers.

Application

Our products offer an exceptional level of control, allowing for the display of intricate motion graphics and vibrant color-shifting effects, as well as high-quality video on a large scale. Whether you need to create 2D or 3D displays, our linear and linear luminaires can do it all with ease. From stunning interior sets to massive video displays covering entire buildings, our products can cater to any size and scale of presentation. With our cutting-edge technology, you can create a truly memorable visual experience that will capture the attention of even the most discerning audience.

Specification

Profile

Output: 10w 12w 15w per meter

The lumen output for RGBW ranges from 32-40lm/w, while the white color has a higher output of 60-65lm/w. This information reveals that the white color is more efficient in terms of luminous output compared to the RGBW option. However, both options can provide adequate light depending on the user's preference and lighting needs.

Optics: 120°view angle

CCT: White Red Green Blue Yellow Amber RGB RGBW

Voltage: DC24V DC48V

Control: DMX system or DALI or ON/OFF

Dimension: L1000*W22*H41mm

Housing: Extruded aluminum with PC diffuser

Finish: High durable surface anodized

Operating temp: -30 to 50°C

Lumen maintenance: 50,000hrs

Certificate: CE ROHS

IP: IP66

Insulation class: Class III

Power supply: Power supply remote, Constant voltage

Mounting: Surface
